1-1/4" Diameter [Ø32] Grab Bar with Snap-On Flange Covers for concealed mounting shall be type 304 stainless
steel alloy 18-8. Tubing shall be 1-1/4" Diameter [Ø32] x 18 gauge (0.048") [1.2]. Snap-on cover shall be 22
gauge (0.03") [0.8]. Flange shall be 1/8" [3] thick and shall be heliarc welded to tubing with a continuous
concealed bead. End flanges shall have two (2) 5/16" diameter [Ø7.5] mounting holes. Center posts (if any) shall
have (2) keyhole slots to ease installation access. All exposed surfaces shall have a satin finish and shall be
protected during shipment with a plastic bag. For optional non-slip surface, add suffix –P (peened).
steel alloy 18-8. Tubing shall be 1-1/4" Diameter [Ø32] x 18 gauge (0.048") [1.2]. Snap-on cover shall be 22
gauge (0.03") [0.8]. Flange shall be 1/8" [3] thick and shall be heliarc welded to tubing with a continuous
concealed bead. End flanges shall have two (2) 5/16" diameter [Ø7.5] mounting holes. Center posts (if any) shall
have (2) keyhole slots to ease installation access. All exposed surfaces shall have a satin finish and shall be
protected during shipment with a plastic bag. For optional non-slip surface, add suffix –P (peened).
